An Introduction to Bartender The Bartender modular underbar system provides a faster and friendlier service for bar staff and customers alike. Bartender's outstanding versatility helps to maximise productivity and accelerate sales. All this plus the highest build specification on the market and sleek, classical good looks makes Bartender a superb investment in your business.
The bar-workstation is a concept pioneered by IMC. Modular in construction, it comprises underbar and, where appropriate, refrigerated units, ergonomically arranged to provide a compact yet highly productive workspace for bar staff.
A typical beer bar-workstation incorporates Bartender and BK top loading bottle coolers to provide both draught beer and plentiful storage for bottles, cans and glasses. This layout is designed for quick, easy service to crowds of thirsty customers, maximising your profits.
|  |
|
 | For a compact, stylish cocktail bar-workstation, take a look at the example shown. Everything is close at hand for mixing, blending and serving. This solution makes it easy for bar staff to provide an efficient and friendly service.
IMC bar-workstations are all about better bar planning, and better bar planning means faster service, happier customers and greater customer loyalty.
|
|
 | Bartender's wide range of modules and accessories offer unlimited options of bar layout to create a solution that meets all your needs. Even curved and angles bars present no problems. Standard corner sections and custom-made infills allow a continuous bar of virtually any shape to be installed.
Individual modules are easy to plan into most schemes. Optional bar supports complete the system. They support the bar top and front while leaving the underbar space clear for bartender units and creating a void for channelling services. Standard bartender units have a depth of 560mm, the work surface depth 475mm.
|
|
The Bartender bar support is used to carry the bar top, support the bar front, and provide a 150mm void for running water, waste and drinks lines.
KCM can provide a complete service to compliment the Bartender range, we are able to take your project from initial conception providing a full design and quotation for not just the supply of the Bartender range but also all the associated enabling works, services, bar fronts, tops, floors, walls, ceilings, finishes and installation providing a single point of contact from start to finish.
|  |
|
IMC Bartender Modules The following modules are available for the Bartender stainless steel modular underbar system, each unit is available in the sizes specified. Bespoke options may be available depending on requirements and circumstances, for help with design, costs and any other queries relating to Bartender please contact us on 01476 593062. |
|
 | Ice Chest Supplied complete with removable dividers, drain trays and 1 1/4" waste trap
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Ice Chest with Covers As per the standard ice chest, with two piece sliding covers
Available in 400mm, 600mm, 800mm, and 1000mm |
|
 | Shelf Unit Capacity of up to 200 pint (60 cl) glasses per metre
Available in 400mm, 500mm, 600mm, 800mm and 1000mm
Unit is also available with wire shelves on support frames in the same dimensions |
|
 | Shelf Drainer As per standard shelf unit with a pressed drainer top, supplied with 1 1/4" waste trap
Capacity of up to 200 pint (60 cl) glasses per metre
Available in 400mm, 500mm, 600mm, 800mm and 1000mm
Unit is also available with wire shelves on support frames in the same dimensions |
|
 | Perforated Worktop Capacity of up to 200 pint (60 cl) glasses per metre
Available in 400mm, 600mm, 800mm and 1000mm
Also available with reinforced top to allow mounting of beer fonts |
|
 | Beer Station Drainer is 600mm above floor, to accomodate low level beer pumps, supplied with 1 1/4" waste trap
Available in 600mm, and 800mm
|
|
 | Basket Rack with Telescopic Slides Holds three 400mm, 450mm or 500mm wide glasswasher baskets
Available in 445mm, 505mm, and 555mm |
|
 | Single Sink With the exception of the 400mm unit, all other sizes have a left hand drainer
All units have a mixer tap set and a 1 1/4" waste trap
An optional door is available on the 400mm and 600mm units.
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Double Sink The 600mm and 800mm have no drainer, the 1000mm unit has a left hand drainer.
All units have a mixer tap set and a 1 1/4" waste trap
Available in 600mm, 800mm and 1000mm |
|
 | Worktop Unit This unit can be used in place of a shelving unit where a speed rail, blender shelf or towel rail is required
Available in 400mm, 600mm, 800mm and 1000mm
|
|
 | Blender Station Unit consists of a standard 400mm sink unit fitted with a blender shelf
Available in 400mm only |
|
 | Till Unit 520mm wide unit cash drawer shelf |
|
 | Waste Unit 400mm wide unit, supplied with bin |
|
 | Storage Cupboard One or two door lockable cupboard with three internal shelves and worktop
Available in 400mm, 600mm (single door), 800mm and 1000mm (double door) |
|
 | Single Drawer Unit Available in 400mm and 600mm with one lockable drawer |
|
 | Three Drawer Unit Available in 400mm and 600mm with three individually lockable drawers |
|
 | Hand Wash Unit Supplied with mixer tap set and 1 1/4" waste trap.
Available in 300mm and 400mm.
Soap and paper towel dispensers are availble as optional extras |
|
 | Bottle Bin Wheeled bottle skip, with stainless steel front panel generally combined with plain or drainer bridge.
Available in 400mm and 600mm with either type of bridge worktop |
|
 | Corner Top 90 degree angle with splashback to link two runs of Bartender at the worktop level
90 degree angle with splashback and wash hand basin to link two runs of Bartender at the worktop level
45 degree angle for use where the bar structure is curved - non standard infills are also available |
|
 | Plain Bridge Suspended between two Bartender units or one unit and a wall, often used over a glasswasher or bottle skip.
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Drainer Bridge As per the standard plain bridge but with a drainer top and 1 1/4 waste trap
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Leg Frame Bartender units are modular and supplied with one leg frame only, adjacent units share one frame between them. Extra leg frames may be required :
- at the end of each straight run of Bartender - where a bridge is introduced into a run |
|
 | Single and double pole leg Supports infill or bridging section at end of run |
|
 | Painted Steel Bar Support 1060mm high standard bar support, other heights are available special order |
|
 | Speed Rail Used on ice chests, sinks or worktops
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Add on speed rail This can be attached to the front of an existing speed rail to double capacity
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Double Speed Rail Used on ice chests, sinks and worktops
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Speed Rail Lock Used on single and double speed rails
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Blender Shelf Fitted to sinks, ice chests, corner units or worktops
Shelf can be either 210mm or 230mm deep
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Towel Rail Used on sinks, hand wash units, corner units and worktops
Available in 400mm, 600mm, 800mm and 1000mm |
|
 | Condiment Set Hangs on splashback, fitted with 1/9 x 65mm GN containers
Available 350mm and 525mm wide |
|
 | Wash Hand Basin Can be inset into worktops, plain bridges or custom made infills
Supplied with mixer tap set and 1 1/4" waste trap |
|
 | Bottle Opener Can be fitted to ice chests, sinks or worktops, includes catcher |
|
 | Single Trim To be attached to the end unit in a run of Bartender |
|
 | Double Trim To join two adjacent Bartender units in a straight run |
|
 | Corner Trim To join two adjacent Bartender units at an angle |
|
 | Fresh Water Dispenser For filtered water |
|
 | Decor Panel Polished stainless steel decor panels provide a clean finish at the end of a run |
|
